Using the Main Menu15
To create custom channel names:
1. From the Main Menu, click
and select Channel Name.
2. Enter a custom name for each channel.
3. Click OK to save changes.
15.1.5 Selecting Cable Type (Advanced)
The default settings in this menu should work well for almost all types of installations. This
menus should only be used to troubleshoot issues with picture quality caused by cabling
with a resistance higher than 10Ω per 100m (330ft). Select the UTP option for any chan-
nels having the issue. In all other installations, use the Coaxial setting. Click OK to save
your changes.
#LX400060; r.35927/36038; en-US
51
