Camera
6
7
8
2
1
5
3
4
1. PIR Sensor: Passive IR motion sensor for more accurate motion recording.
2. Microphone: Built-in microphone underneath camera body.
3. Lens: Camera lens.
4. Night Vision IR: Night vision IR LEDs used for viewing in complete darkness.
5. Speaker: Speaker for two-way audio.
6. Pair: Pairing button. For more details, see āAppendix C: Adding Camerasā on page 57.
7. Antenna: Wireless antenna.
8. Power Cable: Connect the included power adapter to the cable extending from the camera.
11
