Appendix A: System Specifications
General
Description Specification
Transmission Frequency ISM 2,400~2,483.5 MHz
Transmission Power 14dBm
Unobstructed Effective Range 450ft / 150 m (line of sight)
Spread Spectrum FHSS
Modulation Mode GFSK
Operating Temperature 14 ~ 122° Fahrenheit / -10 ~ +50° Celsius
Operating Humidity <85%
Camera
Description Specification
Image Sensor CMOS
Total Picture Pixels 640 x 480pxl (NTSC)
Minimum Illumination 0Lux (IR on)
Night Vision Distance 40 FT
View Angle Diagonal 64°
Power Consumption (Max.) Max 350mA
Power Supply 9V DC
Dimensions
70 mm x 188 mm x 195 mm / 2.8” x 7.4” x7.7”
(with antenna and sunshade)
Weight 0.9lbs / 0.41 kg
LCD Receiver
Description Specification
Display 7” diagonal (LW270X) / 9” diagonal (LW290X)
Supported Resolution 640 x 480 @ 10fps or 320 x 240 @ 25fps
Receiving Sensitivity -81dBm
Power Consumption (Max.) 850mA
Power Supply 5V DC
55
