Lorex LW2700 SERIES User Manual

6. Connect the cable from the power adapter to the 5V DC port on the bottom panel of the
receiver, and then plug in the power adapter to an outlet or surge protector.
POWER
ADAPTER
Fi
g
ure 3.6 Connect the 5V AC ada
p
ter.
7. Slide the power switch on the rear panel to the “ON” position.
Figure 3.7 Power on
the LCD receiver.
*LW2900 Series uses a
slide switch located on
the side
p
anel.
NOTE: Keep the
power cable in
mind when
mounting the LCD
receiver. You can
drill an additional
hole in your
mounting surface
to help conceal
the power cable.
Figure 3.8 LCD receiver mounted under a cupboard
17
