Replacing the Hard Drive19
To install a new hard drive:
1. Insert the 2 hard drive screws closest to the SATA and power ports on the hard drive and tight-
en them half way.
2. Power off the system, and unplug all cabling from the system.
3. Remove the back panel screws (4×). Remove the cover by sliding it backwards.
#LX400113; r. 3.0/56326/56332; en-US 115
