Replacing the Hard Drive21
The system comes with a pre-installed 3.5" SATA hard drive. You can replace the hard drive
with one up to a maximum size of 10TB, and add a second drive if you choose to.
21.1 Removing the Hard Drive
CAUTION
Make sure that the system is OFF and the power adapter is disconnected before removing/installing a hard drive.
To remove the hard drive:
1. Power off the system, and unplug all cabling from the system.
2. Remove the back panel screws (4×). Remove the cover by sliding it backwards.
3. Turn the recorder over carefully. Remove the 2 hard drive screws closest to the edge of the
recorder. Loosen the remaining 2 hard drive screws, but do not remove them.
#LX400117; r. 6.0/57895/57895; en-US 97
