Pan/Tilt/Zoom (PTZ) Cameras19
Pan/Tilt/Zoom (PTZ) cameras are specialty cameras that move according to commands given by
the recorder. You can move PTZ cameras manually using the recorder’s on-screen display, or
create preset locations and patterns for the camera to follow automatically.
19.1 Connecting PTZ Cameras to the Recorder
Lorex HD PTZ cameras connect to your recorder just like any other camera with no need to run
special wiring — these cameras can accept PTZ commands directly through the Ethernet cable.
CAUTION
When the PTZ camera powers on, it will perform an initial diagnostics check. The camera will move around dur-
ing this process, so ensure the camera module is not resting against another object or surface.
To connect Lorex PTZ cameras:
1. Connect the Ethernet cable to one of the video inputs on the recorder.
2. (OPTIONAL) Connect the PTZ camera’s power adapter to a power outlet.
CAUTION
Most PTZ cameras have a higher power requirement than fixed cameras. If you are planning to connect
more than one PTZ camera to the system, check the power requirement in your PTZ camera’s documenta-
tion to ensure you remain within the total PoE power output of the recorder (220W). Connecting the in-
cluded power adapter to your PTZ camera as shown above will force it to draw power from the wall outlet
rather than the recorder’s PoE switch.
19.2 Basic PTZ Controls
Controlling PTZ cameras.
#LX400117; r. 6.0/57895/57895; en-US 91
