Replacing the Hard Drive21
To install a new hard drive:
1. Insert the 2 hard drive screws closest to the SATA and power ports on the hard drive and
tighten them half way.
2. Power off the system, and unplug all cabling from the system.
3. Remove the back panel screws (4×). Remove the cover by sliding it backwards.
#LX400117; r. 6.0/57895/57895; en-US 99
