12.Track warning
Figure1-13
13. Track adjustment mark
Figure1-14
14. Safe operation mode identification
Figure1-15
Track adjustment
Rubber caterpillar chains
Key (" "symbol)
Steel crawler
Drive wheel
Guiding Wheel
Warning
In order to prevent personal injury or deat
h
caused by improper operation, when operatin
g
the machine, please confirm the running stat
e
of the machine and the operation mode shown.
When confirming the running state of th
e
machine, pay attention to the surroundings o
f
the car body and operate slowly.
ISO standard
Guiding Wheel
Drive wheel
