Operation
Operation 3-
15
Start, drive
1. Position the rotary locking pin in the "lock"
position to lo ck the "swivel rack" and "crawler
rack".
2. Press the lo ck lever of the operating handle to the
"release" position, fold up the working de vice, and
make the lower part of the bucket leave th e
ground 20 ~ 40cm.
* Before starting, please confirm the safety
condition of the front, rear and right sides.
* If the shovel and front idler are placed behind
the handle, the vehicle will drive in the
opposite direction to the handle. So please
confirm whether the shovel and front idler
are facing forward or backward. (The
direction of the shovel is forward)
* Lack of confirmation can cause the body to
move in the opposite direction, sometimes
causing injury ac cidents.
3. Use the handle to pull ba ck and lift t he bulldozer.
Warning
Operating direction of driving handle
Body direction
Blade
Blade
Operating direction of driving handle
Body direction
Handle lock lever
Contact
Lock
