Operation control
Operation control 2-
11
When closing, make sure the left hood is locked,
then push ba ck the hood until you hear a click.
When locking, turn the starting key t o the left so
that it is in a horizontal direction.
IMPORTANT
Do not drive with th e rear h ood open. Otherwise,
the rear cover will be damaged.
3. Open and close the left hood
Please remove the rubber pad in the open and closed parts of the left cover and open the open and closed
parts of the pedal.
To open, first open the rear co ver, and then loosen the butterfly nut on the left s ide to r elease the lock.
When closing, close the left hood first, then place the locking metal member in the specified position, and
tighten the butterfly nut by hand.
Put the rubber mat back in its original position.
4. Fuel tank cap
Insert the sta rtin g key into the keyhole and turn left. When the key is in the h orizontal direction, it can be
unlocked.
Carefully close the fuel tank cover, turn th e starting key to the right, and lo ck it when the key is in the
vertical direction.
Lock
Remove
Rear hood
Starting the key
Press the button to open
Rubber
MATS
Left hood
Left
hood
Rear hood
Butterfly nut
1BAABAYAP002A
