3. Cyclotron steering
If you operate the left (right) driving handle forward and the right (left) driving handle backward, turn
right (left).
Up and down the ramp
When driving on the inclined section, make sure that the rotary frame and the track frame are parallel
to each o ther, and fix the rotary frame with the r otary locking pin.
If you are negligent, the vehicle may rotate in the opposite direction, resulting in injury accidents
caused by rollover.
Be sure to extend the wheelbase to the maximum width when driving o n an incline. Driving with a
narrow wheelbase may cause the car to roll over due to uneven ground.
1. When going uphill, lift t he bucket and keep the bottom of the bucket 20 ~ 40cm off the ground before
driving.
2. To descend a steep slope where crawlers are prone to skid, lower the bucket to the ground and push it
down. When descending from a gentle slope, place the bucket at a level that immediately touches the
ground.
3. When going downhill, adjust the throttle handle and drive slowly.
IMPORTANT
When o perating the working device, please put the lo ck lever of the operating handle in the "release"
position, and pull up th e rotating lock pin to release the fix ation.
[Going uphill]
neutral
neutral
neutral
Cyclotron steering
Cyclotron
steering
Warning
neutral
[Going uphill]
