Troubleshooting
ProtoMat E34/E44
72/78
LPKF Laser & Electronics AG | V. 1.0
Type
Description
Messages
Messages present statistical information of the
program. These can be feedback of CircuitPro
PM on certain actions that have been
executed, e.g.: “New document ... created”.
The messages can be displayed or hidden by
clicking on [Messages].
Service messages
Service messages are displayed when
maintenance of the system is due. Contact the
LPKF Service.
The service messages can be displayed or
hidden by clicking on [Service].
Raise selection
Highlights the selected action in the CAM
view.
Example: You draw a rectangle. The
Message pane displays a corresponding
message (e.g. Rectangle Drawn_5 has been
created). If you activate [Raise selection] and
click on the message, the rectangle is
highlighted in the CAM view.
Table 9: Pane Messages
8.2 Actions in case of an error
 Clearing faults
1. Read the error description in the fault monitor.
2. Remedy the fault.
3. For a new initialization, acknowledge the fault if necessary.

The fault has been cleared.
If the faults still exist after initialization, restart the system software. If you have any
questions contact the LPKF Service.
8.3 Fault table
The following table contains possible faults and proposals how to clear them.
Description
Component
Possible cause
Remedial measures
No connection
between system
and PC
System
Missing power
supply
Check the mains cable and plug the
mains plug back into the wall socket.
Click on Machining > Connect.
System switched
off
Switch the main switch at the system
to the ON position.
Click on Machining > Connect.
No data transfer
via the USB cable
Check the USB cable connection
between the system and the PC for
damage or loose connectors.
