V. 1.0 | LPKF Laser & Electronics AG
Searching fiducials (E44 only)
1. Enlarge the search area by increasing the value in the field Search area length.
2. Start the search again by clicking on [OK].
3. Repeat steps one and two if necessary.
The phase Milling Top is started.
The fiducials are searched.
Enlarging the search spiral also increases the time required for searching the
fiducials. So ensure that the material is placed at the same position if possible when
turning it over (if this is not predefined by using the reference-hole system).
Processing the material (Top side)
1. Insert the tool that is displayed.
2. Click on [OK].
The phase Contour Routing is started.
3. Insert the tool that is displayed.
4. Click on [OK].
A message informs you that the production of the printed circuit board is finished.
The material (Top side) has been processed.
After the printed circuit board has been structured, solder resist and legend can be
applied. LPKF offers the systems ProMask and ProLegend for these purposes.
Furthermore, systems for applying solder paste, for assembly, and for soldering the
printed circuit board are available.
6.3.4 Switching off the system
The system is switched off as follows:
Switching off the system
1. Close CircuitPro PM.
2. Use the On/Off switch to switch off the system.
3. Press the Power button to switch off the extraction system.
The system has been switched off.
