7. Function list
7-3
SV-iC5
Function group 1
LED
display
Parameter
name
Min/Max
range
Description
Factory
defaults
Adjustable
during run
Page
F 0 [Jump code] 0/60 This parameter sets the parameter code
number to jump.
1 O 5-5
F 1
[Forward/
Reverse run
disable]
0/2 0 Fwd and rev run enable 0 X 9-8
1 Forward run disable
2 Reverse run disable
F 2 [Accel pattern]
0/1 0 Linear 0 X 9-13
F 3 [Decel pattern]
1 S-curve
F 4 [Stop mode
select]
0/2
0
Decelerate to stop 0 X 9-18
1 Stop via DC brake
2 Free run to stop
F 8
1)
[DC Brake
start
frequency]
0/60 [Hz]
This parameter sets DC brake start
frequency.
It cannot be set below F23 - [Start
frequency].
5.0 X 10-1
F 9 [DC Brake
wait time]
0/60 [sec]
When DC brake frequency is reached, the
inverter holds the output for the setting time
before starting DC brake.
0.1 X 10-1
F10 [DC Brake
voltage]
0/200
[%]
This parameter sets the amount of DC
voltage applied to a motor.
It is set in percent of H33 – [Motor rated
current].
50 X 10-1
F11 [DC Brake
time]
0/60 [sec]
This parameter sets the time taken to
apply DC current to a motor while motor is at
a stop.
1.0 X 10-1
F12 [DC Brake
start voltage]
0/200
[%]
This parameter sets the amount of DC
voltage before a motor starts to run.
It is set in percent of H33 – [Motor rated
current].
50 X 10-2
F13 [DC Brake
start time]
0/60 [sec]
DC voltage is applied to the motor for DC
Brake start time before motor accelerates.
0 X 10-2
F14 [Time for
magnetizing a
motor]
0/60 [sec]
This parameter applies the current to a
motor for the set time before motor
accelerates during Sensorless vector control.
1.0 X 10-11
1) : Set F4 to 1 (Stop via DC brake ) to view this function
