7. Function list
7-4
SV-iC5
Function group 1
LED
display
Parameter
name
Min/Max
range
Description
Factory
defaults
Adjustable
during run
Page
F20 [Jog
frequency]
0/400
[Hz]
This parameter sets the frequency for Jog
operation.
It cannot be set above F21 – [Max
frequency].
10.0 O 10-3
F21 [Max
frequency]
40/400 *
[Hz]
This parameter sets the highest frequency
the inverter can output.
It is frequency reference for Accel/Decel
(See H70)
If H40 is set to 3(Sensorless vector), it can
be settable up to 300Hz *.
60.0 X 9-19
☞
☞☞
☞
Caution : Any frequency cannot be set
above Max frequency.
F22 [Base
frequency]
30/400
[Hz]
The inverter outputs its rated voltage to
the motor at this frequency (see motor
nameplate). In case of using a 50Hz motor,
set this to 50Hz.
60.0 X 9-15
F23 [Start
frequency]
0.1/10
[Hz]
The inverter starts to output its voltage at
this frequency.
It is the frequency low limit.
0.5 X 9-19
F24 [Frequency
high/low limit
select]
0/1 This parameter sets high and low limit of
run frequency.
0 X 9-19
F25
2)
[Frequency
high limit]
0/400
[Hz]
This parameter sets high limit of the run
frequency.
It cannot be set above F21 – [Max
frequency].
60.0 X
F26 [Frequency low
limit]
0/400
[Hz]
This parameter sets low limit of the run
frequency.
It cannot be set above F25 - [Frequency
high limit] and below F23 – [Start frequency].
0.5 X
F27 [Torque Boost
select]
0/1 0 Manual torque boost 0 X 9-17
1 Auto torque boost
F28 [Torque boost
in forward
direction]
0/15 [%] This parameter sets the amount of torque
boost applied to a motor during forward run.
It is set in percent of Max output voltage.
5 X 9-17
To Next Page
