Appendix
A-3
A.2 List of Flags
A.2.1 High-speed link flags
No.
Keyword
Type
Detail
Description
L000000
_HS1_RLINK
Bit
HS link parameter
No.1’s all stations
normally operated
Displays all stations normally operated as specified in
HS link parameter, which will be On if
1.there is no error with all stations specified in
parameter in RUN mode
2.All data block is in normal communication as
specified in parameter.
3.The parameter specified in each station itself is in
normal communication. Run_link will be kept On if
once On until stopped by link disenable.
L000001
_HS1_LTRBL
Bit
After _HS1RLINK
is ON, abnormal
status displayed
This flag will be On if the station specified in parameter
and the data block’s communication status are as
described below with _HSmRLINK flag On,.
1. When the station specified in parameter is not in
RUN mode,
2. When the station specified in parameter is in error,
3. When data block’s communication status specified
in parameter is unstable,
The link trouble will be On if one of those conditions
1,2 and 3 above occurs. And if such a condition is
back to normal, it will be Off.
L000020
~
L00009F
_HS1_STATE
[k]
(k=000~127)
Bit
Array
HS link parameter
No.1, Block No.k’s
general status
displayed
Displays the general status of the communication
information for the specified parameter’s respective data
blocks.
HS1STATE[k]=HS1MOD[k]&_HS1TRX[k]&(~_HSmER
R[k])
L000100
~
L00017F
_HS1_MOD[k]
(k=000~127)
Bit
Array
HS link parameter
No.1, Block No.k
station’s Run
operation mode
Displays the operation mode of the station specified in
parameter’s data block k.
L000180
~
L00025F
_HS1_TRX[k]
(k=000~127)
Bit
Array
Normal
communication
displayed with HS
link parameter
No.1, Block No.k
station
Displays the communication status of parameter’s data
block k to check if normal as specified.
L000260
~
L00033F
_HS1_ERR[k]
(k=000~127)
Bit
Array
HS link parameter
No.1, Block No.k
station’s Run error
mode
Displays the communication status of parameter’s data
block k to check for any error.
L000340
~
L00041F
_HS1_SETBL
OCK[k]
Bit
Array
HS link parameter
No.1, Block No.k
setting displayed
Displays the setting status of parameter’s data block k.
[
Table
1]
List of communication flags based on HS link number
(
HS link No.
1 ~ 12)
* In the case of Dnet and Pnet, Block No. k stands for the station No. of the slave (in order words, it is station
No. k).
