Chapter 4 System Configuration
4.1 System Configuration of Network
4.1.1 XGT Pnet + Smart I/O
Communication system of Pnet I/F modules is as shown below.
Set the Pnet I/F module as master in system and the others have to set as slave module.
To connect LS inverter, Pnet I/F option module have to install applicable product then it will be communicate.
XG5000
N Configurator
GPL-DT4C/C1
GPL-TR2C/C1
GPL-TR4C/C1
GPL-D22C
GPL-D24C
GPL-RY2C
[Figure 4.1] XGT Pnet + Smart I/O diagram
