Chapter 9 P2P
9-3
9.3 Operation Sequence of P2P
Operation sequence of P2P
No.
S/W applied
Operation
Details
1
N Configurator
Execute Configuration tool
Execute N Configurator
2
Set Network Configuration
Refer to Chapter 7 N Configurator Setting (XGL-
PMEB/C)
3
Connect to
communication port
Refer to Chapter 7 N Configurator Setting (XGL-
PMEB/C)
4
Download Network
Configuration
Refer to Chapter 7 N Configurator Setting (XGL-
PMEB/C)
5
XG5000
XG5000 execution
Execute installed XG5000
6
Make new file
Project New project
Setting project name and type
7
Set XG5000 connection
Select applicable connection driver through XG5000
Online Connection settings
8
Connect to XG5000
XG5000 Online Connect
9
IO Information Read
XG5000 Online Diagnosis I/O Information
10
Define P2P project
Specify P2P” on the XG5000 screen
11
Add P2P
Right click the PLC Add item Communication
module setting and set the communication module,
base, slot, P2P number
12
P2P Block Setting
Double-click the cell on the “P2P” screen
1) For Write: specify Read area (CPU area)
2) For Read: specify Save area (CPU area)
13
P2P Parameters Write
Online Write: check applicable P2P and write
14
P2P Enable
Online Communication module setting Enable
Link: enable applicable P2P
[Table 9.3.1] Operation sequence of P2P
