LSIS S100 Series User Manual

Chapter 3. Installation
9
▪ Preinsulated Crimp Terminal Connectors (Bootlace Ferrule) .
Use preinsulated crimp terminal connectors to increase reliability of the control terminal wiring. Refer to the
specifications below to determine the crimp terminals to fit various cable sizes.
P/N
Cable Spec
Dimensions (inches/mm)
Manufacturer
AWG
mm2
L*
P
d1
D
CE002506
26 0.25
10.4
0.4
/
6.0
0.04 / 1.1 0.1 / 2.5
JEONO
(Jeono Electric,
http://www.jeono.com/)
CE002508
12.4
0.5
/
8.0
CE005006
22
0.50
12.0
0.45
/
6.0
0.05
/
1.3
0.125
/
3.2
CE007506
20
0.75
12.0
0.45
/
6.0
0.06
/
1.5
0.13
/
3.4
* If the length (L) of the crimp terminals exceeds 0.5” (12.7mm) after wiring, the control terminal cover may not
close fully.
To connect cables to the control terminals without using crimp terminals, refer to the following illustration
detailing the correct length of exposed conductor at the end of the control cable.
0.2”
