LSIS S100 Series User Manual

Chapter 4. Basic Features
23
Code
Description
15
Stop
Outputs
a
signal at operation command off, and
when
there is no inverter output voltage.
16
Steady
Outputs
a
signal in steady operation.
17
Inverter
l
ine
Outputs
a
signal while the motor is driven by the
inverter line.
18
Comm
l
ine
Outputs
a
signal while the motor is driven by a
commercial power source..
19
Speed
s
earch
Outputs a signal during inverter speed search
operation.
22
Ready
O
utputs signal when the inverter is in stand by
operation and ready to receive an external operation
command.
28
Timer Out
A timer function to operate terminal output after a
certain time by using multi-function terminal block
input..
29
Trip
O
utputs a signal after a fault trip
31
DB Warn %ED
In case of exceeding DB resistor usage r
ate, the signal
changes to on-state.
34
On/Off Control
O
utputs a signal using an analog input value as a
standard.
35
BR Control
O
utputs a brake release signal
.
4.4.2 Fault Trip Output using Multi-Function Output Terminal and Relay
The inverter can output fault trip state using multi-function output terminal (Q1) and relay (Relay 3, 4).
Group
Cod
e
Name LCD Display
Parameter
Setting
Setting Range Unit
OU
30
Fault trip output mode
Trip Out Mode
010
-
bit
34
M
ulti
-
function relay
3
setting
Relay 3 29 Trip - -
35
M
ulti
-
function relay
4
setting
Relay 4 29 Trip - -
53
Fault trip output on delay
TripOut OnDly
0.00
0.00
–
100.00
sec
54
Fault
trip output off delay
TripOut OffDly
0.00
0.00
–
100.00
sec
Q1
Frequency
Run cmd
