LSIS S100 Series User Manual

Chapter 5. Table of Functions
38
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
acceleration
time2
73
11
0h1249
Multi
-
step
deceleration
time2
Dec Time-2 0.0-600.0(s) 30.0 O/A O O
74
11
0h124A
Multi
-
step
acceleration
time3
Acc Time-3 0.0-600.0(s) 40.0 O/A O O
75
11
0h124B
Multi
-
step
deceleration
time3
Dec Time-3 0.0-600.0(s) 40.0 O/A O O
76
11
0h124C
Multi
-
step
acceleration
time4
Acc Time-4 0.0-600.0(s) 50.0 O/A O O
77
11
0h124D
Multi
-
step
deceleration
time4
Dec Time-4 0.0-600.0(s) 50.0 O/A O O
78
11
0h124E
Multi
-
step
acceleration
time5
Acc Time-5 0.0-600.0(s) 40.0 O/A O O
79
11
0h124F
Multi
-
step
deceleration
time5
Dec Time-5 0.0-600.0(s) 40.0 O/A O O
80
11
0h1250
Multi
-
step
acceleration
time6
Acc Time-6 0.0-600.0(s) 30.0 O/A O O
81
11
0h1251
Multi
-
step
deceleration
time6
Dec Time-6 0.0-600.0(s) 30.0 O/A O O
82
11
0h1252
Multi
-
step
acceleration
time7
Acc Time-7 0.0-600.0(s) 20.0 O/A O O
83
11
0h1253
Multi
-
step
deceleration
time7
Dec Time-7 0.0-600.0(s) 20.0 O/A O O
5.4 Expanded Function group (PAR→
→→
→Ad)
In the following table, the data shaded in grey will be displayed when a related code has been selected.
SL: Sensorless vector control (dr.09)
*O/X: Write-enabled during operation, 7/L/A: Keypad/LCD keypad/Common
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
00
-
J
ump Code
Jump Code
1
-
99
24
O/A
O
O
01 0h1301
Acceleration
pattern
Acc Pattern 0 Linear
0: Linear
X/A O O
02 0h1302 Deceleration Dec Pattern 1 S-curve X/A O O
