LSIS S100 Series User Manual

Chapter 5. Table of Functions
88
Code
Comm.
Address
Name
LCD
Display
Setting Range
Initial
Value
Property*
V/F
SL
Ref.
19
ANDOR
20
SWITCH
21
BITTEST
22
BITSET
23
BITCLEAR
24
LOWPASSFILTER
25
PI_CONTORL
26
PI_PROCESS
27
UPCOUNT
28
DOWNCOUNT
87
0h1E57
User function
input18-A
User
Input18-A
0
-
0xFFFF
0
X/A
O
O
88
0h1E58
User function
input18-B
User
Input18-B
0
-
0xFFFF
0
X/A
O
O
89
0h1E59
User function
input18-C
User
Input18-C
0
-
0xFFFF
0
X/A
O
O
90
0h1E5A
User function
output18
User
Output18
-
32767
-
32767
0
-
/A
O
O
5.15 Groups for LCD Keypad Only
5.15.1 Trip Mode (TRP Last-x)
Code Name LCD Display Setting Range Initial Value Ref.
00 Trip type display Trip Name(x) - - -
01 Frequency reference at trip Output Freq - - -
02 Output current at trip Output Current - - -
03
Acceleration/Deceleration
state at trip
Inverter State - - -
04 DC section state DCLink Voltage - - -
05 NTC temperature Temperature - - -
06
Input terminal state 단자대
DI Status - 0000 0000 -
07 Output terminal state DO Status - 000 -
08 Trip time after Power on Trip On Time - 0/00/00 00:00 -
09
10
Trip time after operation start Trip Run Time - 0/00/00 00:00 -
10 Delete trip history Trip Delete?
0 No
1 Yes
