LSIS S100 Series User Manual

Chapter 5. Table of Functions
55
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
6
Idse
7
Iqse
8
Target Freq
9
Ramp Freq
10
Speed Fdb
12
PID Ref Value
13
PID Fdb Value
14
PID Output
15
Constant
62
0h163E
Pulse output gain
TO Gain
-
1000.0
-
1000.0(%)
100.0
O/A
O
O
63
0h163F
Pulse output bias
TO Bias
-
100.0
-
100.0(%)
0.0
O/A
O
O
64
0h1640
Pulse output filter
TO Filter
0
-
10000(ms)
5
O/A
O
O
65 0h1641
Pulse output
constant output 2
TO Const % 0.0-100.0(%) 0.0 O/A O O
66 0h1642
Pulse output
monitor
TO Monitor 0.0-1000.0(%) 0.0 -/A O O
5.8 Communication Function group (PAR→
→→
→CM)
In the following table, the data shaded in grey will be displayed when a related code has been selected.
SL: Sensorless vector control (dr.09)
*O/X: Write-enabled during operation, 7/L/A: Keypad/LCD keypad/Common
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
00
-
J
ump Code
Jump Code
1
-
99
20
O/A
O
O
01 0h1701
Built
-
in
communication
inverter ID
Int485 St ID 1-250 1 O/A O O
02
42
0h1702
Built
-
in
communication
protocol
Int485 Proto
0
ModBus RTU
0: ModBus
RTU
O/A O O
2 LS Inv 485
03
42
0h1703
Built-in
communication
speed
Int485 BaudR
0
1200 bps
3:
9600 bps
O/A O O
1
2400 bps
2
4800 bps
3
9600 bps
4
19200 bps
5
38400 bps
6
56 Kbps
7
115 Kbps
43
04
42
0h1704
Built-in
communication
frame setting
Int485 Mode
0
D8/PN/S1
0:
D8/PN/S1
O/A O O
1
D8/PN/S2
2
D8/PE/S1
3
D8/PO/S1
05
42
0h17
05
Transmission
Resp Delay
0
-
1000(ms)
5ms
O/A
O
O
42
Will not be displayed when P2P and MultiKPD is set.
43
115,200bps
