LSIS S100 Series User Manual

Chapter 5. Table of Functions
61
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
2
x
1
3
x
0.1
4
x
0.0
1
45
49
0h182D
PID 2nd
proportional gain
PID P2-Gain 0.0-1000.0(%) 100.0 X/A O O
5.10 Extension I/O Function Group(PAR→
→→
→AO)
In the following table, the data shaded in grey will be displayed when a related code has been selected.
SL: Sensorless vector control (dr.09)
*O/X: Write-enabled during operation, 7/L/A: Keypad/LCD keypad/Common
코드 통신 번지 명칭 LCD 표시 설정 범위 초기 값 속성*
V/F SL
참조
00 - Jum Code Jump Code 1~99 0 O/A O O
01 0h1A01
V3 input voltage
display
V3 Monitor[V] -12.00 ~ 12.00[V] 0.00 -/A O O
02 0h1A02
V3 input polarity
selection
V3 Polarity
0
Unipolar
0:Unipola
r
X/A O O
1
Bipolar
03 0x1A03
Time constant of V
3
input filter
V3 Filter 0 ~ 10000[ms] 10 O/A O O
04 0x1A04
V
3
Minimum input
voltage
V3 Volt x1 0.00 ~ 10.00[V] 0.00 O/A O O
05 0x1A05
V
3
o
utput
at
Minimum voltage
(%)
V3 Perc y1 0.00 ~ 100.00[%] 0.00 O/A O O
06 0x1A06
V
3
Maximum input
voltage
V3 Volt x2 0.00 ~ 12.00[V] 10.00 O/A O O
07 0x1A07
V
3
o
utput
at
Maximum voltage
(%)
V3 Perc y2 0.00 ~ 100.00[%] 100.00 O/A O O
08 0x1A08
V3 rotation
direction change
V3 Inverting
0
No
0:No O/A O O
1
Yes
09 0x1A09
V
3
quantization
level
V3 Quantizing
0.00 ,
0.04 ~
10.00[%]
0.04 X/A O O
10 0x1A0A
V
3
M
inimum input
voltage
V3 –Volt x1’ -10.00~ 0.00[V] 0.00 O/A O O
11 0x1A0B
V
3
o
utput
at
Minimum voltage
(%)
V3 –Perc y1’
-100.00 ~
0.00[%]
0.00 O/A O O
12 0x1A0C
V
3
M
aximum input
voltage
V3 –Volt x2’ -12.00~ 0.00[V] -10.00 O/A O O
13 0x1A0D
V
3
o
utput
at
Maximum voltage
(%)
V3 –Perc y2’
-100.00 ~
0.00[%]
-100.00 O/A O O
14 0x1A0E
V
4
input
voltage
display
V4 Monitor[V] 0.00 ~ 12.00[V] 0.00 -/A O O
