LSIS S100 Series User Manual

Chapter 5. Table of Functions
89
5.15.2 Config Mode (CNF)
Code Name LCD Display Setting Range Initial Value Ref.
00 Jump code Jump Code 1-99 42
01 Keypad language selection Language Sel 0 : English 0 : English
02 LCD constrast adjustment LCD Contrast - -
03 Multi keypad ID Multi KPD ID 3-99 3
10 Inverter S/W version Inv S/W Ver - -
11 LCD keypad S/W version Keypad S/W Ver - -
12 LCD keypad title version KPD Title Ver - -
20 Status window display item Anytime Para 0 Frequency 0: Frequency
21 Monitor mode display item1 Monitor Line-1 1 Speed 0: Frequency
22 Monitor mode display item2 Monitor Line-2 2 Output Current 2:Output Current
23 Monitor mode display item3 Monitor Line-3
3 Output Voltage
3:Output Voltage
4 Output Power
5 WHour Counter
6 DCLink Voltage
7 DI State
8 DO State
9 V1 Monitor(V)
10 V1 Monitor(%)
13 V2 Monitor(V)
14 V2 Monitor(%)
15 I2 Monitor(mA)
16 I2 Monitor(%)
17 PID Output
18 PID Ref Value
19 PID Fdb Value
20 Torque
21 Torque Limit
23 Speed Limit
24 Monitor mode initialization Mon Mode Init
0 No
0:No
1 Yes
30 Option slot 1 type display Option-1 Type 0 None 0:None
31 Option slot 2 type display Option-2 Type 6 Ethernet 0:None
32 Option slot 3 type display Option-3 Type 9 CANopen 0:None
40 Parameter initialization Parameter Init
0 No
1 All Grp
2 DRV Grp
3 BAS Grp
