LSIS S100 Series User Manual

Chapter 4. Basic Features
19
Voltage and Current Analog Output Setting Details
Code
Description
AO.30 AO3 Mode
Select a constant value for output.
The following
example for output
voltage
setting.
S
etting
Function
0
Frequency
Outputs operation frequency as a standard. 10V output is
made from the frequency set at dr.20(Max Freq)
1
Output
Current
10V output is
made from 200% of inverter rated
current (heavy load).
2
Output
Voltage
Sets the outputs based on the inverter output
voltage. 10V output is made from a set voltage in
bA.15 (Rated V).
If 0V is set in bA.15, 200V/400V models output 10V
based on the actual input voltages ( 240V and 480V
respectively).
3
DC Link Volt
Outputs inverter DC link voltage as a standard.
Outputs 10V when the DC link voltage is 410Vdc for
200V models, and 820Vdc for 400V models.
4
Torque
O
utputs
the
generated torque as a
standard.
Outputs 10V at 250% of motor rated torque.
5
Ouput Power
Monitors output watt
age
. 200% of rated output is
the maximum display voltage (10V).
6
Idse
O
utputs the maximum voltage at 200% of no
load
current.
7
Iqse
O
utputs the maximum voltage at 2
50% of rated
torque current

=






−






8
Target Freq
O
utputs set frequency as a standard.
O
utputs 10V
at the maximum frequency (dr.20).
9
Ramp Freq
O
utputs frequency calculated with Acc/Dec
function as a standard. May vary with actual output
frequency. Outputs 10V.
12
PID Ref Value
O
utputs command value of a PID controller as a
standard. Outputs approximately 6.6V at 100%.
13
PID Fdk Valu
e
O
utputs feedback volume of a PID controller as a
standard. Outputs approximately 6.6V at 100%.
14
PID Output
Outputs output value of a PID controller as a
standard. Outputs approximately 10V at 100%.
15
Constant
O
utputs OU.05 (AO1 Const %) value as a s
tandard.
AO.31 AO3 Gain,
AO.32 AO3 Bias
A
djust
s
output
value
and offset.
I
f frequency is selected as
an
output item, it
will operate as shown below.
3 =


× 3 + 3
The graph below illustrates the analog voltage output (AO3) changes depend
on Ao.31 (AO3 Gain) and Ao.32 (AO3 Bias) values. Y-axis is analog output
voltage (0–10V), and X-axis is % value of the output item.
