Calibration
BPD17 pH / Redox Monitor
Operating Guide
- 37 -
Sensor Condition
The BPD17 is capable of analysing the result of the
pH electrode offset and slope calibration and indicate
to the user the condition the electrode is in.
Good – The electrode is operating within set
parameters.
Replace Soon – The electrode is getting towards
the end of is operating life.
Replace – The electrode is exhausted and should
be replaced.
Cannot be edited, only available when units set to pH
in the channel setup menu.
Temperature Offset Calibration
The temperature offset calibration enables the user
to adjust the temperature reading to match a known
input.
The current temperature reading can be seen in the
pop-up window and is adjusted by pressing the up
and down arrows. When the reading is correct press
the enter button to store the calibration. The
calculated offset is shown in the next menu entry.
/ – Adjust the Reading Up or Down
EXIT
– Cancel
– Save Calibration
Temp Offset Value
The temperature offset value currently being used.
The value will change depending on the result of the
temperature offset calibration.
Cannot be edited
