Lucent Technologies Lineage
®
2000 ECS/GPS Battery Plant J85500G-2
Issue 6 May 1999 Installation 4 - 17
Test Procedure
Note: Reset the BD alarm on the controller to 3.0 VDC below
the float voltage. Reset the HVSD level to 3.0 VDC above the
float voltage when the margining feature is enabled. See
J85500D-x assembly drawing for DIP switch settings.
1. Open the distribution door and set SW500.2, on the BMD1
LVD/R Fuse Circuit Pack to the closed position. This will
enable the compensation feature. Close the distribution
door.
2. Check to see that the green LED on the 216A Control Unit
is ON.
3. Verify that there are no alarms being generated on the ECS
Controller.
4. Heat thermistors with INDIRECT airflow from a heat
gun. Heat applied directly to the thermistor could cause
damage.
5. Observe the following steps:
A minor fuse alarm (MNF) should be issued at
Table 4-D: SW500 Reference
Conditions 216A Status Plant Voltage
Compensation
enabled
Margin level Compensation Temperature in degrees Celsius
SW500.2 SW500.4 0 - 25 25 - 53 53 - 75 75+ +75 to <65
10
Enabled
V FLT
+72mV/°C
V FLT
-72mV/°C
V FLT
-2.0VDC
V FLT
-6.0VDC
V FLT
-2.0VDC
11
Enabled
No Change
V FLT
-72mV/°C
V FLT
-2.0VDC
V FLT
-6.0VDC
V FLT
-2.0VDC
*0 *1
Disabled
No Change
0 0 Disabled No Change
SW500.1 SW500.3 Low Voltage Disconnect/Reconnect Voltage Levels
*1 *1 -42.5 VDC
0 0 -40.5 VDC
“1” represents switch in closed position
“0” represents switch in open position
“V FLT represents uncompensated plant float voltage
Notice that “+” or “-” determines which direction the voltage compensates
* indicates factory default
