Table 2-F: List 31 Fuse Panel
The List 31 panel contains 8 individual fuse blocks, each accommodating a single fuse. Refer
below for fuse specifications. Load fuses are ordered on a job basis, separately from the battery
plant order.
Load Fuse (Five Configurations Orderable)
Type Size
Range
(Amps)
List
Quantity
(maximum 8)
Order Information
Cartridge
9/16x2 inch
13/16x3 inch
1-30
35-60
H
J
1-8
1-8
J85500G-2,
L-21,
(1-8) L-H
(1-8) L-J
Specify positions from
left to right, numbered 1-8
Table 2-G: List 32 Fuse Panel
The List 32 panel contains 4 individual fuse blocks
(70-100A), each accommodating a single fuse. Refer
below for fuse specifications. Load fuses are ordered
on a job basis, separately from the battery plant
order.
Type
Range (Amps)
Order
Informationfor a
Fuse Panel
NON 70-100 J85500G-2, L-32
Table 2-H: List 33 Fuse Panel
The List 33 panel contains 2 individual fuse blocks (110-200A), each
accommodating a single fuse and monitoring shunt. Fuses and shunts are
furnished with the panel per lettered lists below.
Load Fuse
Type Capacity
(Amps) Order Information
NON
110
125
150
175
200
J85500G-2, L-33
L-AY
L-AZ
L-BA
L-BB
L-BC
