Lucent Technologies Lineage
®
2000 ECS/GPS Battery Plant J85500G-2
3 - 32 Engineering, Planning and Ordering Issue 6 May 1999
G-sheets show Cabling Diagrams (CADs), define terminal
designations and wiring for installer connections. This
information is duplicated in the Installer Figures of the
T-drawing.
H-sheets are included in some SD-drawings to provide Block
Diagrams (BDs) that are helpful in understanding complex
circuits.
J-sheets are used for Circuit Pack Schematics (CPSs), if any are
included in the SD. Most circuit packs, however, are
documented on separate schematic drawings, some of which are
proprietary and are not generally accessible.
Ordering
Information
The J85500G-2 battery plant is ordered with List (L) numbers
and Equipped With (E/W) items. See Table 3-H.
A sample order for a G-2 plant containing nine 50-ampere
rectifiers, a CP2 microprocessor board, fourteen 30-ampere
breakers, two 175-ampere breakers, capacitor charge
switch/feature, one 24-position 1-30-ampere fuse block and stile
strips in the initial bay and three 50-ampere rectifiers, a fourth
rectifier shelf, two 200-ampere fuses and stile strips in a
supplementary bay with blank panels covering the upper half of
the bay would look like the example below.
Note: Multiple List 20, 30 through 34 distribution panels on a
single bay must be itemized together. Specify breakers or fuses
as part of a specific panel. Also, List 4, 5, 7, 8, 9 and K10 should
be ordered separately from the equipment since they are shipped
in separate containers.
