Lucent Technologies Lineage
®
2000 ECS/GPS Battery Plant J85500G-2
2 - 28 Product Description Issue 6 May 1999
1/4"diameter ring terminal. Place it on the negative
terminal of the battery.
Each kit provides two thermistors and associated wiring to
connect to the 216A Control Module. The retrofit kit contains
two paddle thermistors to monitor one string of batteries. If more
than one string of batteries is to be monitored, order a thermistor
kit for each additional battery string.
Figure 2-12: Plant Bus Bars With Optional List 2 Low Voltage Disconnect
Optional Low Voltage
Disconnect/Reconnect
(LVD/R) Contactor
Charge
Bus
Charge
Bus
Charge
Return
Bus
Charge
Return Bus
Section A-A
Plant 600 Amp
Shunt
Front of
Frame
Discharge
Return Bus
Battery
Bus
(Optional
with LVD/R)
