Issue 6 May 1999 Engineering, Planning and Ordering 3 - 21
Low-Voltage
Disconnect/
Reconnect
Feature
Low-voltage battery disconnect/reconnect is available as an
option on the ECS plant. For this feature, two disconnect levels
are available: 40.5 and 42.5 volts. The tolerance on disconnect
levels is +/- 0.5 volts. Based on the discussion above on Battery
Sizing and Battery Voltage, fill in the following information.
Is Low-Voltage Battery Disconnect/Reconnect required?
_____(yes or no)
If “yes”, specify the disconnect level _____(40.5 or 42.5)
Emergency
disconnect
(Reserved for future use.)
Table 3-F: Load Feeder Wire And Fuse/Breaker Size
Circuit Number List 2 Drain
Minimum Wire Gauge
Selected Wire
Gauge
Fuse/breaker
Rating
(Ampacity) (Voltage Drop)
1
Table 3-G: Minimum Wire Gauge (Ampacity) - All Strings
String Number
Minimum Wire
Gauge
Selected Wire
Gauge
1
2
3
4
5
6
