Lucent Technologies Lineage
®
2000 ECS/GPS Battery Plant J85500G-2
Issue 6 May 1999 Product Description 2 - 1
2 Product Description
Plant
Specifications
Table 2-A: Lineage
®
2000 Battery Plant Specifications (Model
J85500G-2)
Input Voltage 180-264 volts ac, single phase (208/220/240 volts ac nominal)
Input Frequency 47-63 Hertz (50/60 Hertz nominal)
Operating Voltage 40-60 volts dc (48 volts nominal)
Float Voltage 47-58.5 volts dc (48 volts dc nominal)
Plant Current Rating 600 amperes
Plant Shunt 600 amperes maximum at 50 millivolts
LVD/R Voltage
Settings
40.5 or 42.5 volts dc
Controller:
ECS Basic: 113B
Microprocessor option circuit pack: CP2
Datalogger option circuit pack: CP3
or Galaxy basic: 48V rectifier control
Rectifier Shelf
Assembly
4 maximum, each mounts 3 rectifiers
Rectifiers
Type: Lineage® 2000 SR50/-48V
Rating: -48 volts nominal, 50 amperes
12 maximum
Circuit Breakers
Type: KS22010, KS22012
Available ratings: 5, 10, 20, 30, 45, 60, 80, 100, 125, 175, 225,
300, 400, 500, 600 amperes
Fuses
Type: 74, KS-19870, cartridge, NON
Available ratings: 1-200 amperes
Temperature
32-122 degrees Fahrenheit
(0-50 degrees Celsius)
