Lucent Technologies Lineage
®
2000 ECS/GPS Battery Plant J85500G-2
Issue 6 May 1999 Installation 4 - 7
3. Set HV shutdown level(s)
4. Set BD alarm level
5. Run office alarm wiring
6. Run other controller wiring
7. Set-up other optional circuit packs
Check and set the low-voltage disconnect/reconnect, if
provided, at the desired voltage level. See Figures 4-3 or 4-4 for
the location of the disconnect voltage select jumpers, J505.1 and
J505.2 on CP5 Fuse Board. Plug these jumpers across pins 1 and
2 of their respective connectors to provide a disconnect voltage
of 42.5 +/- 0.5 volts. To provide a disconnect voltage of 40.5
+/-0.5 volts, plug the jumpers across pins 2 and 3 of their
respective connectors. Refer to the ECS controller manual for
Table 4-C: Installation Reference Documents
Step
Procedure Reference Document*
A
Unpacking, handling
and frame installation
J85500G-2 drawing
B Battery stand assembly Battery manual
C Initial battery charge
Battery manual
Rectifier manual
D
Cable support and
ground system
Job application
drawings
E
Controller setup and
LVD test
Controller manual
F
AC wiring, rectifier
installation and rectifier
test
Rectifier manual,
J85500G-2 drawing and
T-82673-31 drawing
G Load wiring
J85500G-2 drawing and
T-82673-31 drawing
H
Battery connections,
disconnect installation
and test
J85500D-2 drawing,
T-82670-31 drawing,
T-82673-31 drawing
and battery manual
I Controller test Controller manual
J Load turn-up
Load equipment
documentation
*See Section 3, Documentation References
