Fuse panels The List 30 through 36 fuse panels are shown in Figures 2-5
through 2-11. Refer to Tables 2-E through 2-K for fuse
specifications and order information. Each load fuse position has
a corresponding indicating alarm fuse. If a load fuse blows, its
corresponding alarm fuse automatically opens, which issues an
alarm signal MJF (FAJ) and leaves a visual indication. All
indicating alarm fuses are 70 G type 1/2 amp and are furnished
with the panel. Remove them by pushing in on the fuse cap and
rotating it counterclockwise. Fuse ordering information is
available from Tables W and Z on J85500G-2 drawing.
Table 2-D: List 20 Circuit Breaker Panel
With Optional Capacitor Charge Feature Panel
Circuit breakers operate and provide an alarm during electrical trip.
The List 20 panel contains 21 slots for circuit breakers and an
optional capacitor charge feature.* The panel bus bar is sized for 600
ampere capacity.
Circuit Breaker Specification
Capacity
(Amps)
Type
(Heinemann)
Slots Occupied
Max. No. Per
L-20 Panel
Order Information
J85500G-2, L-20
5
10
20
30
45
60
80
100
15
KS220101
1
1
1
1
1
1
1
1
1
21
21
21
21
21
21
21
21
21
L-AA
L-AB
L-AC
L-AD
L-AE
L-AF
L-AG
L-AH
L-AJ
100
125
175
225
300
400
500
600
KS22012
1.5
1.5
1.5
1.5
3
3
4.5
4.5
4
4
4
4
2
2
1
1
L-AL
L-AM
L-AP
L-AR
L-AU
L-AV
L=AW
L-AX
*Capacitor charge feature occupies 4 slots on the List 20 panel and is
ordered as L-CA.
