Lucent Technologies Lineage
®
2000 ECS/GPS Battery Plant J85500G-2
2 - 18 Product Description Issue 6 May 1999
Figure 2-9: List 34 (70 to 200A) fuse panel
70-100A
FUSE BLOCK
(2 PLACES)
100-200A
FUSE BLOCK
Figure 2-10: List 35 (70 to 600A) fuse panel
70-600A
Fuse Block
