Lucent Technologies Lineage 2000 User Manual

Lucent Technologies Lineage
®
2000 ECS/GPS Battery Plant J85500G-2
Issue 6 May 1999 Engineering, Planning and Ordering 3 - 35
B
Optional equipment in addition to List A and a second List
10 to provide ac prewire to the fourth rectifier shelf
assemblies.
Lists AA-AJ provide circuit breakers for List 20 with the following ampere
capacity:
AA
5 ampere breaker
AB
10 ampere breaker
AC
20 ampere breaker
AD
30 ampere breaker
AE
45 ampere breaker
AF
60 ampere breaker
AG
80 ampere breaker
AH
100 ampere breaker
AJ
15 ampere breaker
AL
100 ampere breaker with shunt
AM
125 ampere breaker with shunt
AP
175 ampere breaker with shunt
AR
225 ampere breaker with shunt
AU
300 ampere breaker with shunt
AV
400 ampere breaker with shunt
AW
500 ampere breaker with shunt
AX
600 ampere breaker with shunt
CA
Provides a capacitor charge feature for List 20 breaker panel
to precharge high inrush loads.
30
Fuse panel for twenty-four 1 to 30A load fuses
31
Fuse panel for eight 1 to 60A load fuses
Lists H and J provide fuse mounting for List 31 with the following ampere
range:
H
1 to 30A fuse mounting
J
31 to 60A fuse mounting
32
Fuse panel for two 110 to 200A load fuses
33
Fuse panel for two 110 to 200A load fuses
34
Fuse panel for two 70 to 100A load fuses
35
Fuse panel for two 70 to 600A load fuses
Table 3-H: Ordering Guide J85500G-2 ECS 600 Ampere
-48 Volt Battery Plant
List Number Description of Equipment and Features
