Lucent Technologies MERLIN LEGEND Release 6.1 Maintenance And Troubleshooting

MERLIN LEGEND Communications System Release 6.1
Maintenance and Troubleshooting
555-661-140
Issue 1
August 1998
Page 4-47
Module Problems
Console Display/Instructions Additional Information PC
The screen below appears when the Restore fails. Try again, and be
sure to specify the correct slot.
Internal Loopback Test
This test checks communication between the processor and the module being
tested. If you have not read ‘‘Module Test Process’’ on page 4-34
, do so before
continuing.
5HVWRUH6ORW YY 
xx = slot number entered in Step 2
5HVWRUH&RPSOHWH
([LW
5HVWRUH6ORW YY 
xx = slot number entered in Step 2
5HVWRUH)$,/('
%RDUG0LVPDWFK
([LW
