MERLIN LEGEND Communications System Release 6.1
Maintenance and Troubleshooting
555-661-140
Issue 1
August 1998
Page E-4
Installing the Control Unit Housing
Figure E-2. Installing the Control Unit Housing
MERLIN LEGEND
TO DETATCH:
SLIDE TO ALIGN ARROWS
TO ATTACH:
ALIGN ARROWS. SLIDE
TO COMPLETE CIRCLE.
d
Line Up With the
Semicircle on Inside
of Front Panel
Right Hand
Side Panel
Slide Tongues in
and Push Front Panel Up
Front Panel
