Lucent Technologies MERLIN LEGEND Release 6.1 Maintenance And Troubleshooting

MERLIN LEGEND Communications System Release 6.1
Maintenance and Troubleshooting
555-661-140
Issue 1
August 1998
Page 5-74
Conclusion of Hardware Maintenance
are in the same time zone. When they are not, time zone differences must also
be considered.
Conclusion of Hardware
Maintenance
Installing the Control Unit Housing (Release
2.1 or Later)
After you have completed maintenance and troubleshooting on Release 2.1 or
later, follow the steps below to reinstall the control unit housing.
Installing the Top Cover
To install the top cover, see Figure 5–1 and follow these steps.
!Be sure the cords have been pressed through the wire managers at
the base of the modules.
!Hold the top cover with the hooks facing you.
!Engage the tabs at the rear of the top cover with the carrier.
!Lower the top cover, so that the legs lock into the vents on the
module.
Installing the Front Cover
To install the front cover, see Figure 5-76 and follow these steps.
!Hook the top of the front cover onto the top cover.
!Push down on the bottom of the front cover until it locks securely
on the base of the wire manager on the modules.
