Lucent Technologies MERLIN LEGEND Release 6.1 Maintenance And Troubleshooting

MERLIN LEGEND Communications System Release 6.1
Maintenance and Troubleshooting
555-661-140
Issue 1
August 1998
Page 4-128
Checking System and Slot Status
!Remove the processor, the power supply, and all other modules
from the faulty carrier. (If you prefer to remove the cords first, make
sure that they are labeled.)
!Put the modules aside, in order, so that you can reinstall them later
in the replacement carrier.
!Remove all modules from the carriers to the right of the faulty
carrier.
!Starting with the
rightmost carrier, loosen the four screws that
secure the four corners of the carrier to the backboard.
!Slide the carrier to the right until the connector disengages from the
carrier to the left.
! Pull the carrier away from the wall so that the screws slip through
the large screw holes.
! Repeat Steps 8–10 until the faulty carrier is removed.
Replacing the Carrier
After removing the faulty carrier, use the steps below as a guideline for installing
a new carrier.
!Install the replacement carrier(s). See
Installation for instructions.
!Replace the modules with all cords connected as they were before.
Checking System and Slot Status
In addition to checking error logs, and the access log, and running module tests,
you can request System Status and Slot Status information for each module.
