Lucent Technologies MERLIN LEGEND Release 6.1 Maintenance And Troubleshooting

MERLIN LEGEND Communications System Release 6.1
Maintenance and Troubleshooting
555-661-140
Issue 1
August 1998
Page 4-80
800 NI-BRI Module Problems
Console Display/Instructions Additional Information PC
!Observe the status screens below.
The screen below appears while the test is running.
While the test is running, the LEDs are in the following states:
In Release 4.0, the screen below appears only if all 16 communication
paths connected to the slot pass the tests.
The screen below appears if fewer than 16 communication paths are
programmed on the module or if one or more communication paths fail.
On a module with fewer than 16 programmed paths, the screen will show
2. for all successful paths, error codes for all failed paths, and $'0,1 for
any path that was not programmed. Before proceeding, record all the
error codes on this screen, in the correct order.
3URYLVLRQLQJVORW YY 
xx = slot number entered in Step 2
3URYLVLRQLQJLQSURJUHVV
([LW
GREEN Blinks to indicate the test is running.
YELLOW Flashes on and off while calls are being established
and disconnected.
RED Stays on until Layers 1–3 are initialized for all
programmed communication paths on the module.
3URYLVLRQLQJVORW YY 
xx = slot number entered in Step 2
$OO/LQHV3DVVHG
([LW
