MERLIN LEGEND Communications System Release 6.1
Maintenance and Troubleshooting
555-661-140
Issue 1
August 1998
Page 1-2
Equipment
Detailed information about system programming is included in System
Programming
and in System Programming and Maintenance (SPM).
You can use either a DOS PC or a Master Controller (MCII or MCIII) to run
SPM. To connect a PC to the control unit, you need a 355AF adapter and a
D8W-87 cord.
NOTES:
1. Onsite programming maintenance is preferred if it is feasible; remote
programming overrides onsite programming, except when onsite
backup or restore is in progress. See “On-Site Programming
Maintenance” on page 1–3 and “Remote Programming Maintenance”
on page 1–6 for details.
2. In Release 6.0 and later systems (Hybrid/PBX mode) where systems
are private networked and only one system has public switched
networked trunks, you must use the Remote Access feature in order to
access SPM on private networked systems. For details, see “Remote
Programming Maintenance” on page 1–6.
Tools and Documentation
In addition to the maintenance terminal, you need the following tools and
documentation:
■ Trouble report documentation
■ Troubleshooting guide
■ NSAC contact name
■ EIA breakout box
■ Digital voltmeter (KS-20599 or equivalent)
■ 110/66-type punchdown tool
■ Dracon TS21 or equivalent touch-tone telephone for testing
■ Assorted flathead and Phillips-head screwdrivers
■ Long-nosed and regular pliers
