Lucent Technologies SLC-2000 Access System Central Office Terminal User Manual

3-42 Issue 4 February 1997
363-208-011
Cabling, Wiring, and Assembly
Figure 3-25. DS1 IN (1 - 16) Connections
Wiring Side
P160
P168
BL/W
O/W
GR/W
BR/W
S/W
BL/R
O/R
GR/R
BR/R
S/R
BL/BK
O/BK
GR/BK
BR/BK
S/BK
BL/Y
RING
W/BL
W/GR
W/BR
W/S
R/BL
R/0
R/GR
R/BR
R/S
Y/BL
W/O
BK/BL
BK/O
BK/GR
BK/BR
BK/S
TIP
DSXI 01
DSXI 02
DSXI 03
DSXI 04
DSXI 05
DSXI 06
DSXI 07
DSXI 08
DSXI 09
DSX1 10
DSXI 11
DSXI 12
DSXI 13
DSXI 14
DSXI 15
DSXI 16
1
20
16
35
