363-208-011
Cabling, Wiring, and Assembly
Issue 4 February 1997 3-43
Figure 3-26. DS1 IN (17 - 28) Connections
Wiring Side
P161
P167
BL/W
O/W
GR/W
BR/W
S/W
BL/R
O/R
GR/R
BR/R
S/R
BL/BK
O/BK
RING
W/BL
W/GR
W/BR
W/S
R/BL
R/0
R/GR
R/BR
R/S
W/O
BK/BL
BK/O
TIP
DSXI 17
DSXI 18
DSXI 19
DSXI 20
DSXI 21
DSXI 22
DSXI 23
DSXI 24
DSXI 25
DSX1 26
DSXI 27
DSXI 28
1
20
12
31
