10 Issue 1.0 August 1998
363-208-011 Appendix 2
NE00676-70 Local Alarm Relay Unit Installation Procedure
Figure 1. Mounting Positions for LARU on COT or RT
Baffle (above UIP on COT)
Fan Assembly (above UIP on RT)
LARU
LARU
