363-208-011, Appendix 3
Test Head Installation
Issue 1 November 1998 A3-7
Step 7:
Mate the MLT Control RJ11 connector to the first 955-7000xxx126
cable.
Step 8:
Mate the Monitor/Talk RJ11 connector to the second 955-7000xxx126
cable.
Step 9:
Connect the first 955-7000xxx126 cable MLT Control RJ11 connector
to the POTS VF circuit as determined by the customer.
Step 10:
Connect the second 955-7000xxx126 cable Monitor/Talk RJ11 con-
nector to the POTS VF circuit as determined by the customer.
Remote Test Head Turn-Up
General
These procedures install the circuit packs in the Lucent Technologies RTH-7000
or the General Signal Networks Tau-tron
ngRTH
test head.
NOTE:
Refer to the Lucent Technologies RTH-7000 or the General Signal Net-
works Tau-tron related documents for detailed installation and trouble-
shooting instructions for their test head panels.
Circuit Pack Installation
Step 1:
Unpack the test head circuit packs from their shipping carton(s).
Step 2:
Install the Main Power Module (MPM) in the left-most slot of the test
head.
Step 3:
Install the fuse and fuse receptacle in the MPM. Push on the recepta-
cle and turn clockwise approximately one-quarter turn.
Requirement:
Yellow ALARM LED extinguishes.
Step 4:
Install the remainder of the circuit packs, as required, in the order
shown below and wait for the FAULT LED to extinguish before insert-
ing the next pack. The slots progress from left to right in the shelf.
Test Controller Module (TCM)
Wideband Digital Module (WDM) *
Wideband Transmission Module (WTM) *
Access and Termination Module (ATM) *
Voiceband Transmission Module (VTM) *
Voiceband Amplifier Module (VAM)
Analog Multimeter Module (AMM)
* If listed on the job specification.
