Lucent Technologies SLC-2000 Access System Central Office Terminal User Manual

A3-8 Issue 1 November 1998
363-208-011, Appendix 3
Test Head Installation
NOTE:
Refer to customer provided information to determine which circuit packs
are to be installed in the test head. See the note and Table 1-2 on Page 3
for more information.
Requirement: The LED on the inserted circuit pack illuminates. Red FAULT LED
on MPM extinguishes in approximately 10 seconds after the
insertion of each circuit pack.
Step 5: Repeat Step 4 until all of the provided circuit packs are installed.
Step 6: Verify that the FAULT and ALARM LEDs on the MPM are extin-
guished.
SLC-2000 Access System Circuit Packs
General
These procedures verify that the software and the circuit packs in the SLC -2000
Access System shelves that are required for the operation of the Lucent
Technologies RTH-7000 or the General Signal Networks Tau-tron ngRTH test
head are present. See Table 1-4 for the circuit packs that must be present in the
SLC -2000 Access System for the operation of the test head.
Table 1-4. SLC-2000 Access System Circuit Packs
Pack Location Description
SMU ARM Shelf System Memory Unit
LAN ARM Shelf Link to Alarms and Networks
PDC ARM Shelf Provisioning and Display Controller
MDC MDS Metallic Distribution Controller
T8U * MDS TR-08 Unit
PTU MDS Power and Test Unit
* The T8U is required for TR-08 operation only.
