Lucent Technologies SLC-2000 Access System Central Office Terminal User Manual

A3-14 Issue 1 November 1998
363-208-011, Appendix 3
Test Head Installation
Figure 1-6. Test Head Analog Wiring P14
50
45
40
35
30
26 1
5
10
15
20
25
W/BL
W/GR
R/0
R/GR
R/BR
BK/BL
TIP
BL/W
GR/W
O/R
GR/R
BL/BK
BR/R
RING
Wiring Side
P14
p/o 955-7000xxx036 Cable Assembly
N/C
TAP 1 A F
N/C
N/C
N/C
N/C
N/C
N/C
TAP 1 B F
TAP 1 B E
N/C
N/C
N/C
TAP 1 A E
Bypass Pair
TAP 1 C F
TAP 1 C C
N/C
N/C
RJ/11 (P4)
RJ/11 (P3)
N/C
N/C
N/C
N/C
N/C
TAP 1 A F
N/C
N/C
N/C
N/C
N/C
N/C
TAP 1 B F
TAP 1 B E
N/C
N/C
N/C
TAP 1 A E
Bypass Pair
TAP 1 C F
TAP 1 C E
N/C
N/C
RJ/11 (P4)
RJ/11 (P3)
N/C
N/C
N/C
N/C
W/BL
BL/W
W/BL
BL/W
Note:
N/C = not used or required
Jumper
Jumper
